2026 Star EV J-Model 2

Specifications

Motor

Power System Type	48-volt DC
Motor Controller	250-amp solid-state controller
Top Speed	Level ground: 14.5-19.5 mph (23.3 kph +/- 31.4 kph)

Electric

Electrical	System: 48-volt
Starter	Pedal

Battery

Battery	Six, 8-volt deep cycle
Battery Charger Type	48 V PowerWise QE, 120 VAC, UL and CSA

Drivetrain

Drivetrain	Motor shaft direct drive
Transmission	Differential with helical gears
Gear Shifter	Body mounted forward-neutral-reverse
Axle Capacity, Rear	12.44:1
Features	Programmable Golf Modes: Coastal, Mild Hill, Steep Hill

Chassis

Frame Type	Welded Steel with Powder-Coat Protection
Chassis	Injection Molded TPO

Suspension

Steering	Self-compensating rack and pinion
Front Suspension	Leaf springs with hydraulic shock absorbers
Rear Suspension	Leaf springs with hydraulic shock absorbers

Brakes

Brake System Type	Rear wheel mechanical self-adjusting drum
Parking Brake	Self-compensating, single point engagement

Wheels & Tires

Front Wheel	Track: 34.5 in (88 cm)
Rear Wheel	Track: 38.5 in (98 cm)
Front Tire	Hole-in-One 18 x 8.50-8 (4-ply rated)
Rear Tire	Hole-in-One 18 x 8.50-8 (4-ply rated)

Dimensions

Overall Length)	93.0 in (236 cm
Overall Width	47.0 in (119 cm)
Overall Height	No canopy: 47.0 in (119 cm) (top of steering wheel) | With canopy: 68.5 in (174 cm) (top of sun canopy)
Wheelbase	66.5 in (169 cm)
Ground Clearance	4.0 in (10 cm) at differential
Dimensions	Outside Clearance Circle: 19.0 ft (5.8 m)

Capacities

Seating Capacity	2-person
Payload Capacity	800 lb (360 kg)
Towing Capacity	3 E-Z-GO golf cars with approved permanent tow bar

Weights

Weight	Without batteries: 963 lb (437 kg)
Curb Weight	800 lb (360 kg)

Colors

Colors

Almond, Black, Bright White, Burgundy, Electric Blue, Flame Red, Forest Green, Inferno Red, Ivory, Orange, Metallic Charcoal, Patriot Blue (custom colors also available)

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
